IEI Mustang-M2BM-MX2 – Vision Accelerator Card
• IEI – Mustang-M2BM-MX2 – Vision Accelerator Card
• Deep learning inference accelerating M.2 BM key card with 2 x Intel® Movidius™ Myriad™ X MA2485 VPU, M.2 interface 22 mm x 80 mm, RoHS
• Compact size M.2 2280 card. (22x80mm)
• Low power consumption, approximate 7.5W for two Intel Movidius Myriad X VPU.
• Supported OpenVINO toolkit, AI edge computing ready device
• Two Intel Movidius Myriad X VPU can execute two topologies simultaneously.
Description
Mustang-M2BM-MX2
Intel Vision Accelerator Design with Intel Movidius VPU
A Perfect Choice for AI Deep Learning Inference Workloads
Powered by Open Visual Inference & Neural Network Optimization (OpenVINO) toolkit
- Compact size M.2 2280 card. (22x80mm)
- Low power consumption, approximate 7.5W for two Intel Movidius Myriad X VPU.
- Supported OpenVINO toolkit, AI edge computing ready device
- Two Intel Movidius Myriad X VPU can execute two topologies simultaneously.
Intel Distribution of OpenVINO toolkit
Intel Distribution of OpenVINO toolkit is based on convolutional neural networks (CNN), the toolkit extends workloads across multiple types of Intel platforms and maximizes performance.
It can optimize pre-trained deep learning models such as Caffe, MXNET, and ONNX Tensorflow. The tool suite includes more than 20 pre-trained models, and supports 100+ public and custom models (includes Caffe*, MXNet, TensorFlow*, ONNX*, Kaldi*) for easier deployments across Intel silicon products (CPU, GPU/Intel Processor Graphics, FPGA, VPU).
Features
- Operating Systems
- Ubuntu 16.04.3 LTS 64bit, CentOS 7.4 64bit , Windows 10 64bit
- OpenVINO toolkit
- Intel Deep Learning Deployment Toolkit
- – Model Optimizer
- – Inference Engine
- Optimized computer vision libraries
- Intel Media SDK
- Current Supported Topologies:
- AlexNet,
- GoogleNetV1/V2,
- Mobile_SSD, MobileNetV1/V2,
- MTCNN Squeezenet1.0/1.1,
- Tiny Yolo V1 & V2, Yolo V2,
- ResNet-18/50/101 (more variants are coming soon)
- High flexibility, Mustang-M2BM-MX2 develop on OpenVINO toolkit structure which allows trained data such as Caffe, TensorFlow, and MXNet to execute on it after convert to optimized IR.
Applications
Machine Vision | Smart Retail |
Surveillance | Medical Diagnostics |
Specification
Model Name | Mustang-M2BM-MX2 |
Main Chip | 2 x Intel Movidius Myriad X MA2485 VPU |
Operating Systems | Ubuntu 16.04.3 LTS 64bit, CentOS 7.4 64bit, Windows 10 64bit |
Dataplane Interface | M.2 BM Key |
Power Consumption | Approxinate 7.5W |
Operating Temperature | 0°C~55°C (In FLEX-BX200) |
Cooling | Passive Heatsink |
Dimensions | 22 x 80 mm |
Support Topology | AlexNet, GoogleNetV1/V2, Mobile_SSD, MTCNN, Squeezenet 1.0/1.1, Tiny Yolo V1 & V2, Yolo V2, ResNet-18/50/101 |
Operating Humidity | 5% ~ 90% |
*Standard PCIe slot provides 75W power, this feature is preserved for user in case of different system configuration
Ordering Information
Part No. | Description |
Mustang-V100-MX8-R10 | Computing Accelerator Card with 8 x Movidius Myriad X MA2485 VPU, PCIe Gen2 x4 interface, RoHS |
Mustang-V100-MX4-R10 | Computing Accelerator Card with 4x Intel Movidius Myriad X MA2485 VPU, PCIe Gen 2 x 2 interface, RoHS |
Mustang-MPCIE-MX1 | Deep learning inference accelerating miniPCIe card with 2 x Intel Movidius Myriad X MA2485 VPU, miniPCIe interface 30mm x 50mm, RoHS |
Mustang-M2AE-MX1 | Computing Accelerator Card with 1 x Intel Movidius Myriad X MA2485 VPU,M.2 AE key interface, 2230, RoHS |
Mustang-M2BM-MX2-R10 | Deep learning inference accelerating M.2 BM key card with 2 x Intel Movidius Myriad X MA2485 VPU, M.2 interface 22mm x 80mm, RoHS |
