Honeywell CentraLine: Building Management HMI Panel PCs

Commercial buildings today contain a range of technical subsystems to automate or monitor the different aspects of a building.

Most common systems include:

honeywell logo 1

Heating, Ventilation, and Air Conditioning Systems (HVAC)

• Fire and Smoke Detection Systems

 Intrusion Detection and Video Surveillance Systems

• Access Control Systems

• Lighting and Blind Control Systems

Centraline logo 1

BVM Ltd have been supplying the HMI hardware as the computing interface for Centraline’s HVAC integrated heating controllers (Hawk, Eagle Hawk) since 2008. Over the years, our HMI has been provided in various formats – 5.7”, 7”, 8” being the more commonly used formats – but also in the larger sizes of 10”, 12” and 15”.

Powered by Intel CPU’s, our range of building management HMI Panel PCs offer fast, responsive performance, they have an IP65 rating for protection against water and dust and they are fully compatible with Honeywell CentraLine control units and other HTML5 serving controllers and BMS thanks to our new and improved “Easy Install Control Panel” software.

BVM Easy Install Control Panel

BVM Easy Install Control Panel

Controller IP Address

Enter the Honeywell / Centraline controller IP address
Save the IP address to favourites if you need to connect to multiple controllers

HMI Panel PC IP Address

Set the Panel PC IP address (LAN 1)

BMS IP Address*

If you are connecting to a building management system for remote access to the controller set the BMS IP address (LAN 2)
*HMI Panel PC with Dual LAN required

Set Rendering Engine

Choose your preferred browser
(IE10, IE11 or Google Chrome)

Commit and Reboot

Save and Exit

HPC070SC‐FP2807A

JetWay 03

7.0″ TFT Fanless Touch Panel Computer

Intel Bay Trail-M N2807 1.58GHz Dual Core CPU

2Gb 1333mhz DDR3 RAM

32Gb Industrial Grade SSD Hard Drive

1 x Gigabit LAN | 4 x USB

Datasheet

HPC080SC‐FP2807A

JetWay 03

8.0″ TFT Fanless Touch Panel Computer

Intel Bay Trail-M N2807 1.58GHz Dual Core CPU

2Gb 1333mhz DDR3 RAM

32Gb Industrial Grade SSD Hard Drive

1 x Gigabit LAN | 4 x USB

Datasheet

HPC-101SC-FP1900B

HPC 101SC FP1900B 45D

10.1″ TFT Fanless Touch Panel Computer

Intel Bay Trail-M J1900 2.0GHz Quad Core CPU

4Gb 1333mhz DDR3 RAM

32Gb Industrial Grade SSD Hard Drive

2 x Gigabit LAN | 4 x USB

Datasheet

HPC-121SC-2930-4G

HPC 121SC 2930 4G 45D 1

12.1″ TFT Fanless Touch Panel Computer

Intel Bay Trail-M N2930 1.83GHz Quad Core CPU

4Gb 1333mhz DDR3 RAM

32Gb Industrial Grade SSD Hard Drive

2 x Gigabit LAN | 4 x USB

Datasheet

HPC-156SC-FP1900B

HPC 101SC FP1900B 45D

15.6″ TFT Fanless Touch Panel Computer

Intel Bay Trail-M J1900 2.0GHz Quad Core CPU

4Gb 1333mhz DDR3 RAM

32Gb Industrial Grade SSD Hard Drive

2 x Gigabit LAN | 4 x USB

Datasheet

HPC-238SC-FP1900B

HPC 101SC FP1900B 45D

23.8″ TFT Fanless Touch Panel Computer

Intel Bay Trail-M J1900 2.0GHz Quad Core CPU

4Gb 1333mhz DDR3 RAM

32Gb Industrial Grade SSD Hard Drive

2 x Gigabit LAN | 4 x USB

Datasheet

We like to make life easier ….
BVMs building management solutions with our new and improved “easy access control panel” software are intended to save our customers time and let them concentrate on installing the hardware, knowing that the technical software configuration is taken care of by our easy install control panel software.

For more information you can either call us directly on +(0) 1489 780 144 and talk to one of the team, use the below form or  E-mail us at sales@bvmltd.co.uk

centraline3

BVM: Providing smart industrial PC hardware

to meet the demands of today’s technology challenges …….

Since its inception in 1989, BVM has grown steadily and is recognised for its abilities as a System Integrator and the supply of industrial PC (IPC) components, sub-assemblies and its own-brand products to a customer base in a range of industry verticals.

BVM’s core ability is the development of PC solutions – integrating  power supply’s, memory, storage, TFT displays, cellular modems for remote connectivity, GPS, multiple channel capture cards, operating systems – and where required, custom designed electronics.

BVM has a range of embedded O/S configuration services, implementing standard / generic images through  to fully customised versions where user accounts and application configurations are pre-installed within the O/S. BVM’s image service is inclusive of maintenance services wherever & however required for a products complete lifetime.


With 30 years experience of supplying custom boards and embedded systems to industries as diverse as power generation, motorway tolling, advanced security and railways, BVM has built up a wealth of knowledge and experience which can be applied to your project ensuring minimum technical issues arise and help reduce the time to market which is so important in the current fast moving environment..

QualityQuality

The company prides itself in its quality management system which has been ISO9001 certified since 1995. This insures a consistent high quality product is produced on time and with full tracebility. All units are CE certified, fully tested and ready to run.



How to ProceedContact

To find out more about how BVM can help your company please click here and leave a brief outline of your requirements or call us today to discuss the possibilities.

Quite often, we’re the manufacturer behind the solutions you know

Whether we’re utilising our own manufacturing & production facilities here in Southampton – or our ecosystem of partners in Asia, BVM can cope with any size or complexity of batch manufacturing. Our production team are highly motivated with a flexible “can do” attitude ensuring consistent quality and on-time delivery.
