Description
The Winmate Defence Console Rack Panel PC Series combines powerful 12th Generation Intel® processing with rugged military-grade construction to deliver reliable computing for defence, naval, command and control, surveillance, and mission-critical applications. Available in display sizes ranging from 15″ to 32″, these rack-mounted panel PCs are engineered for deployment in demanding environments where performance, durability, and compliance are essential. Powered by the Intel® Core™ i5-1235U processor, the series provides efficient hybrid-core performance for advanced data processing, monitoring, communications, and tactical operations. Designed to meet stringent military standards, these systems offer resistance to shock, vibration, electromagnetic interference, and harsh environmental conditions, making them ideal for defence platforms, naval vessels, mobile command centres, and secure control rooms.
The Defence Console Rack Panel PC Series delivers a scalable solution across multiple screen sizes while maintaining a consistent platform architecture, simplifying deployment, maintenance, and system integration across defence infrastructure.
Key Features
- Intel Core i5-1235U 12th Generation Processor with speeds up to 4.40GHz
- Available in display sizes from 15″ to 32″
- Rugged fanless design for reliable operation in mission-critical environments
- Anti-corrosion housing for naval, maritime, and harsh defence applications
- Projected Capacitive (P-CAP) multi-touch screen technology
- Compliant with MIL-STD-810G/F environmental standards
- Compliant with MIL-STD-461E/F military EMC standards
- Flush rack and rack-mount mechanical designs available
- Convenient front-access On-Screen Display (OSD) controls
- Wide-range AC 110~240V power input as standard
- Optional isolated DC 9~36V power input for vehicle and defence platforms
- Integrated ambient light sensor with automatic brightness adjustment
- Designed for command and control, surveillance, communications, and defence console applications
Speficication
| Specification | Details |
|---|---|
| Display Sizes | 15″, 17″, 18.5″, 19″, 21.5″, 24″ and 32″ |
| Processor | Intel® Core™ i5-1235U |
| CPU Speed | 3.30GHz Base, Up to 4.40GHz Turbo |
| Touchscreen | Projected Capacitive (P-CAP) |
| Cooling | Fanless |
| Housing | Anti-Corrosion Chassis |
| Mounting | Flush Rack / Rack Mount |
| OSD Controls | Front Accessible Controls |
| Brightness Control | Automatic via Built-In Light Sensor |
| AC Power Input | 110 ~ 240VAC |
| Optional DC Input | Isolated 9 ~ 36VDC |
| MIL Standard Compliance | MIL-STD-810G/F, MIL-STD-461E/F |
| Certifications | CE, FCC |
| Applications | Defence, Naval, Surveillance, Command & Control |
The Winmate Defence Console Rack Panel PC Series is available in multiple display sizes and configurations to suit a wide range of defence and mission-critical applications. For the latest pricing, stock availability, and full technical datasheets, please get in touch with our team.
Compliance Standards
| Standard | Region / Framework | Tests (Default) | Optional Tests |
|---|---|---|---|
| MIL-STD-461G | USA EMC Standard | CE101, CE102, RE101, RE102, CS118 | CS101, CS114, CS115, CS116, RS101, RS103 |
| STANAG 4370 / AECTP-501 | NATO EMC Standard | NCE01, NCE02, NRE01, NRE02, NCS12 | NCS01, NCS07, NCS08, NCS09, NRS01, NRS02 |
| MIL-STD-810H | USA Environmental Standard | Vibration (514.6), Humidity (507.6), Transit Drop (516.6) | — |
| STANAG 4370 / AECTP-401/402/404 | NATO Environmental Standard | — | Vibration, Shock (Procedure I), Drop & Topple Tests |
Available Models & Display Sizes
| Screen | Model Number | Variant / Interface | Certifications |
|---|---|---|---|
| 15″ | R15IAD3S-MLA3FP | Standard Defence Console | MIL-STD-810G/F, MIL-STD-461E/F |
| 17″ | R17IAD3S-MLA1FP | Standard Defence Console | MIL-STD-810G/F, MIL-STD-461E/F |
| 17″ | R17IAD3S-RKA1ML | MIL-DTL-38999/1 Defence Connector | MIL-STD-810G/F, MIL-STD-461E/F |
| 18.5″ | W18IAD3S-MLA3FP | Standard Defence Console | MIL-STD-810G/F, MIL-STD-461E/F |
| 19″ | R19IAD3S-MLA3FP | Standard Defence Console | MIL-STD-810G/F, MIL-STD-461E/F |
| 19″ | R19IAD3S-RKA3ML | MIL-DTL-38999/1 Defence Connector | MIL-STD-810G/F, MIL-STD-461E/F |
| 19″ | R19IAD3S-MLA3-89 | High Performance / i7 Platform | MIL-STD-810G/F, MIL-STD-461G |
| 17″ | R17IAD3S-MLA1-89 | High Performance / i7 Platform | MIL-STD-810G/F, MIL-STD-461G |
| 21.5″ | W22IAD3S-MLA3FP | Standard Defence Console | MIL-STD-810G/F, MIL-STD-461E/F |
| 24″ | W24IAD3S-MLA2FP | Standard Defence Console | MIL-STD-810G/F, MIL-STD-461E/F |
| 24″ | W24IAD3S-RKS1ML | Enhanced Integration Variant | MIL-STD-810G/F, MIL-STD-461E/F |
| 32″ | W32IAD3S-MLA3FP | Standard Defence Console | MIL-STD-810G/F, MIL-STD-461E/F |
