AAEON GENE-ASL5 Amston Lake x7000RE 3.5″ SBC

Product Name: AAEON GENE-ASL5 Amston Lake x7000RE 3.5″ SBC
Motherboard Form Factor: 3.5″ SubCompact Board
CPU: Intel Atom Processors x7000RE Series
RAM: DDR5 4800 MHz, Dual Channel SODIMM x 1, Up to 16GB
Expansion: Full size mPCIe/mSATA, M.2 3052 B-Key x 1, M.2 2230 E-Key x 1
Other features: Dual Intel 2.5GbE, SATA III x 1, GPIO x 8-bit, USB 3.2 Gen 2 x 2, USB 2.0 x 4, DC Input 9-36V, Supports WiTAS

Model

Clear

SKU: GENE-ASL5 Category: 3.5" Single Board Computers Tags: 2.5GbE, 9~36V, DDR5, GPIO / DIO, Intel Amston Lake, IoT, Multi Display - Triple, OS: Linux, OS: Windows, OS: Windows 11, TPM 2.0, Wide Temp Brand: AAEON Technology Inc

Description

The AAEON ENE-ASL5 Amston Lake x7000RE 3.5″ SBC is a compact industrial motherboard equipped with Intel Atom® x7000RE processors. It supports up to 16GB of DDR5 RAM and offers versatile expansion options, including full-size mPCIe, mSATA, and M.2 slots. The board features dual 2.5GbE ports, HDMI, VGA, and LVDS display outputs, and has a wide DC input range of 9-36V. It also supports WiTAS, making it ideal for industrial applications requiring efficient networking and expandability in a small form factor.

Key Features

Intel Atom® Processors x7000RE Series Processors
DDR5 4800 MHz, Dual Channel SODIMM x 1, Up to 16GB
LVDS Dual Channel 18/24 bit x 1, VGA x 1, HDMI x 1
Intel® 2.5GbE x 2 , SATA III x 1, GPIO x 8bit
USB 3.2 Gen2 x 2 , USB2.0 x 4
Full size mPCIe/mSATA
M.2 3052 B-Key x 1, M.2 2230 E-Key x 1
DC Input 9-36V
Supports WiTAS

Specification

SYSTEM
Form Factor	3.5″ SubCompact Board
CPU	Intel Atom® Processors x7000RE Series for the Edge: Intel Atom® x7213RE (2C, 2.0 GHz, 9W) Intel Atom® x7433RE (4C, 1.5 GHz, 9W) Intel Atom® x7835RE (8C, 1.3 GHz, 12W)
Chipset	Integrated with Intel® SoC
Memory Type	DDR5 4800, Single Channel SODIMM x 1, Max.16GB, Non-ECC
BIOS	UEFI
Wake on LAN	Yes
Watchdog Timer	255 Levels
SECURITY	TPM2.0
RTC BATTERY	Lithium Battery 3V/240mAH
Dimension (L x W)	5.75″ x 4″ (146mm x 101.7mm), 0.94 lbs (0.43 kg)
OS SUPPORT	Windows 10/11 (64bit) Ubuntu 22.04/Kernel 5.15.0–25-generic
Power
POWER REQUIREMENT	+12V
POWER SUPPLY TYPE	AT/ATX
CONNECTOR	Phoeix 2-pin Connector
POWER CONSUMPTION	Intel® Atom x7835RE, DDR5 16GB x1, 3.20A@ +12V (TYPICAL) Intel® Atom x7835RE, DDR5 16GB x1, 4.80A@ +12V (MAX)
Display
CONTROLLER	Intel® UHD Graphics
LVDS/eDP	LVDS x 1, Dual Channel 18/24bit, up to 1920 x1080
DISPLAY INTERFACE	HDMI 1.4 x 1, up to 3840 x2160 @30Hz VGA x 1, up to 1920 x1080
MULTIPLE DISPLAY	Up to 3 Simultaneous Displays
Audio
CODEC	Realtek ALC897
AUDIO INTERFACE	Line-In / Line-Out / Mic (Audio function not available for WiTAS SKU)
SPEAKER	—
EXTERNAL I/O
ETHERNET	Intel® Ethernet Controller I226, 2.5GbE x 2
USB	USB3.2 Gen 2 x 2
SERIAL PORT	—
VIDEO	HDMI 1.4 x 1, VGA x 1
INTERNAL I/O
USB	USB2.0 x 4
SERIAL PORT	COM1 , COM2 (RS232/422/485, supports 5V/12V/RI) COM3 , COM4 (RS232)
VIDEO	LVDS x 1 Inverter x 1 (12V/2A)
SATA	SATA 6.0 Gb/s x 1 +5V SATA Power Connector x 1
AUDIO	Audio Header x 1 (Optional, Audio function not available for WiTAS SKU)
DIO/GPIO	GPIO 8-Bit
SMBUS/I2C	Default: SMBus
TOUCH	—
FAN	4pins Smart Fan x1
SIM	Nano SIM x 1
FRONT PANEL	HDD LED, PWR LED, Power Button, Buzzer, Reset
EXPANSION
MINI PCI-E/MSATA	Full-size mSATA / mPCIe x 1 (Default: mSATA, select by BIOS)
M.2	M.2 2230 E-Key x 1 (PCIe 3.0 [x1] + USB2.0) M.2 3052 B-Key x 1 (USB3.2 Gen2 + USB2.0)
OTHERS	—
ENVIRONMENT & CERTIFICATION
OPERATING TEMPERATURE	WiTAS 2: -40°F ~ 185°F (-40°C ~ 85°C)
STORAGE TEMPERATURE	-40°F ~ 185°F (-40°C ~ 85°C)
OPERATING HUMIDITY	0% ~ 90% relative humidity, non-condensing
MTBF (HOURS)	333,008
EMC	CE/FCC Class A

Ordering Information

PART NUMBER	GENE-ASL5W2-A10-0001	GENE-ASL5W2-A10-0002	GENE-ASL5W2-A10-0003
CPU	Intel Atom^® x7433RE	Intel Atom^® x7213RE	Intel Atom^® x7835RE
Display	VGA x 1 HDMI x 1 LVDS x 1	VGA x 1 HDMI x 1 LVDS x 1	VGA x 1 HDMI x 1 LVDS x 1
LAN	2.5GbE x 2	2.5GbE x 2	2.5GbE x 2
COM	4	4	4
Storage	SATA x 1	SATA x 1	SATA x 1
Expansion Slot	M.2 B-Key 3052 x 1 M.2 E-Key 2230 x 1 MiniCard x1	M.2 B-Key 3052 x 1 M.2 E-Key 2230 x 1 MiniCard x1	M.2 B-Key 3052 x 1 M.2 E-Key 2230 x 1 MiniCard x1
TPM	2.0	2.0	2.0
Power	9~36V	9~36V	9~36V
Temp	-40^°C ~ 85^°C	-40^°C ~ 85^°C	-40^°C ~ 85^°C
Others	GPIO x 8, Touch Controller, SMBUS	GPIO x 8, Touch Controller, SMBUS	GPIO x 8, Touch Controller, SMBUS

AAEON 3.5″ SBCs

Datasheet

Download(295 KB)
