ASRock Industrial IMB-1318 14th/13th/12th Gen Micro ATX Motherboard

  • Product Name: ASRock Industrial IMB-1318
  • Motherboard Form Factor: Micro ATX
  • CPU: Intel 14th/13th/12th Gen Core Processors with H610 chipset
  • RAM: 2 x 288-pin Long-DIMM DDR5 4800/5600 MHz, up to 96GB (48 GB per DIMM)
  • Expansion: 1 x PCIe x16 (Gen5), 1 x PCIe x4 (Gen3), 2 x PCIe x1 (Gen3), 4 x USB 3.2 Gen1, 6 x USB 2.0, 1 x M.2 Key E, 1 x M.2 Key M, 6 x COM, 4 x SATA3
  • Other features: 2 x Intel 1 Gigabit LAN, Supports Triple display (3 x HDMI 1.4b), ATX PWR (8+24 Pin)
ADD TO QUOTE
Product Compare
SKU: IMB-1318 Categories: , Tags: , , , , , , , , , , , , , Brand:

Description

The ASRock Industrial IMB-1318 is a high-performance Micro ATX motherboard designed for Intel 14th, 13th, and 12th Gen Core processors with the H610 chipset. It supports up to 96GB of DDR5 RAM, features versatile expansion options including PCIe Gen5 and multiple M.2 slots, and provides robust connectivity with dual Intel Gigabit LAN, USB 3.2, and COM ports. Ideal for industrial applications, it supports triple-display output via HDMI and offers reliable power with ATX (8+24 Pin) support.

Key Features

  • Intel 14th/13th/12th Gen (Raptor Lake-S Refresh/Raptor Lake-S/Alder Lake-S) Core Processors with H610 chipset
  • 2 x 288-pin Long-DIMM DDR5 4800/5600 MHz, up to 96GB (48 GB per DIMM)
  • 1 x PCIe x16 (Gen5), 1 x PCIe x4 (Gen3), 2 x PCIe x1 (Gen3), 4 x USB 3.2 Gen1, 6 x USB 2.0, 1 x M.2 Key E, 1 x M.2 Key M, 6 x COM, 4 x SATA3
  • 2 x Intel 1 Gigabit LAN
  • Supports Triple display, 3 x HDMI 1.4b
  • ATX PWR (8+24 Pin)

Specification

Processor System
CPU Intel® 14th/13th/12th Gen (Raptor Lake-S Refresh/Raptor Lake-S/Alder Lake-S) Core™ Processors, up to 65W
Chipset Intel® H610
Socket LGA 1700
BIOS AMI SPI 256 Mbit
Form Factor
Dimensions Micro-ATX (9.6-in x 9.6-in x 1.58-in, 24.4 cm x 24.4 cm x 4.02 cm)
Memory
Technology Dual Channel DDR5 4400/5600 MHz*
*Actual memory frequency depends on the CPU types and
DRAM modules, for more information refer to
https://www.asrockind.com/en-gb/index.php?route=newsblog/%20faq&faq_id=90%20technical%20FAQ
Capacity 96GB (48GB per DIMM)
Socket 2 x 288-pin Long-DIMM
Graphics
Controller Intel® UHD Graphics
HDMI HDMI 1.4b
Max resolution up to 4096 x 2160@30Hz
LVDS Dual channel 24 bit up to 1920 x 1200@60Hz
(Connector shared with eDP) (BOM option)
eDP Max resolution up to 1920 x 1080@60Hz
(Connector shared with LVDS) (BOM option)
MultiDisplay Triple Display
Expansion Slot
PCIe 1 x PCIe x16 (Gen5)
1 x PCIe x4 (Gen3)
2 x PCIe x1 (Gen3)
M.2 1 x M.2 (Key E, 2230) with CNVi for Wireless
Audio
Interface Realtek ALC897 HD, High Definition Audio. Line-In, Line-Out, Mic-In
Ethernet
Controller/ Speed LAN1: Intel® I210AT with 10/100/1000 Mbps
LAN2: Intel® I219V with 10/100/1000 Mbps
Connector 2 x RJ-45
Rear I/O
HDMI 3 x HDMI 1.4b
Ethernet 2 x 1 Gigabit LAN
USB 4 x USB 3.2 Gen1
2 x USB 2.0
Audio 3 (Line-In/Line-Out/Mic-In)
Serial Port COM1 (RS-232/422/485), COM2 (RS-232)
Internal Connector
USB 4 x USB 2.0 (1 x 2.54 pitch header, 2 x USB 2.0 Type-A vertical con)
COM COM3, COM4, COM5, COM6 (RS-232)
Parallel 1 (shared with GPIO)
GPIO 8 x GPI, 8 x GPO (shared with LPT header)
LVDS 1 (Connector with LVDS/eDP signal, switch by BIOS) (BOM option)
Speaker Header 1
PS/2 1 x PS/2 header
Thunderbolt header 1
Security
TPM TPM Header
Storage
M.2 1 x M.2 (Key M, 2242/2280/25110) with PCIe Gen3 x1 for SSD
SATA 4 x SATA3
Watchdog Timer
Output From Super I/O to drag RESETCON#
Interval 256 Segments, 0, 1, 2, …255sec
Power Requirements
Input PWR ATX PWR (24+8-pin)
Power On AT/ATX Supported
– AT : Directly PWR on as power input ready
– ATX : Press button to PWR on after power input ready
Environment
Operating Temp -20ºC ~ 70ºC
Storage Temp -40° C ~ 85° C
Operating Humidity 5% ~ 90%
Storage Humidity 5% ~ 90%
