AAEON GENE-ARH6 15th Gen Core Ultra 2 (Arrow Lake) 3.5″ SBC
- Product Name: AAEON GENE-ARH6
- Motherboard Form Factor: 3.5″ SBC
- CPU: Intel Core Ultra (Series 2), 15th Gen (Arrow Lake)
- RAM: DDR5 6400 MHz, Dual Channel SODIMM x 2, up to 96GB
- Expansion: M.2 2280 M-Key x 1, M.2 3052 B-Key x 1, M.2 2230 E-Key x 1
- Other Features: Triple LAN, HDMI/eDP/DP/LVDS display outputs, USB 3.2 Gen 2 x 2, USB 2.0 x 4, 8-bit GPIO, SATA 6Gb/s, 9–36V DC input
Description
The AAEON GENE-ARH6 is a compact and high-performance 3.5” single board computer (SBC) powered by 15th Gen Intel® Core™ Ultra (Arrow Lake) processors. Designed for demanding industrial and embedded applications, it supports up to 96GB of high-speed DDR5 memory and features advanced I/O connectivity, triple LAN support, and a versatile range of expansion options.
Ideal for edge AI, industrial automation, digital signage, and smart retail deployments, the GENE-ARH6 delivers next-generation computing power in a space-efficient form factor. With multiple display outputs and wide voltage input support (9–36V DC), it offers robust performance and flexible integration into a variety of embedded systems.
Key Features
- Intel Core Ultra processors (Series 2)
- DDR5 6400 MHz, Dual Channel SODIMM x 2, up to 96GB
- LVDS x 1, eDP x 1, DP x 1, HDMI x 1
- LAN x 3, SATA 6Gb/s x 1, 8-bit GPIO
- USB 3.2 Gen 2 x 2, USB 2.0 x 4
- M.2 2280 M-Key x 1, M.2 3052 B-Key x 1, M.2 2230 E-Key x 1
- DC Input 9 ~ 36V
Specification
| Category | Specification |
| Form Factor | 3.5″ SubCompact Board |
| CPU | Intel® Core™ Ultra Processors (Series 2): |
| • Ultra 7 255H (16C/16T, up to 5.1 GHz, 28W) | |
| • Ultra 5 225H (14C/14T, up to 4.9 GHz, 28W) | |
| • Ultra 7 255U (12C/14T, up to 5.2 GHz, 15W) | |
| • Ultra 5 225U (12C/14T, up to 4.8 GHz, 15W) | |
| Chipset | Integrated with Intel® SoC |
| Memory | DDR5 6400, Dual Channel SODIMM x 2, up to 96GB (Non-ECC) |
| Supports up to 2x 48GB DDR5 up to 5600 MT/s | |
| BIOS | UEFI |
| Wake on LAN | Yes |
| Watchdog Timer | 255 Levels |
| Security | TPM 2.0 |
| RTC Battery | Lithium Battery 3V/240mAH |
| Dimensions | 5.75″ x 4″ (146mm x 101.7mm), 0.88 lb. (0.4kg) |
| OS Support | Windows® 10/11 (64-bit), Linux Ubuntu 24.04.2 (Kernel 6.11.0-25-generic) |
| Power Requirement | +9V to +36V DC (Optional: +12V), supports ERP |
| Power Supply Type | AT/ATX, supports 3-pin ATX |
| Power Connector | Phoenix 2-pin Connector (Colay 4-pin optional) |
| Power Consumption | 5.44A (Typical) / 9.56A (Max) @ +12V (with Intel® Core™ Ultra 7 + DDR5 48GB x2) |
| Graphics Controller | Intel® Arc™ Graphics, Intel® Graphics |
| LVDS / eDP | LVDS x 1 (1920×1080), eDP 1.4b x 1 (3840×2160 @60Hz) |
| Display Outputs | HDMI 2.1 x 1 (8Kx4K@60Hz or 4Kx2K@120Hz), DP 2.0 x 1 (7680×4320@60Hz, 30bpp, supports DP++) |
| Multiple Displays | Supports up to 4 simultaneous displays |
| Audio Codec | Realtek ALC897 |
| Audio Interfaces | Line-in / Line-out / MIC (Audio not available for WiTAS SKU) |
| Ethernet | 1 x Intel® I219 1GbE, 2 x Intel® I226 2.5GbE (Intel® vPro® support with Ultra 7 265H) |
| USB (External) | USB 3.2 Gen 2 x 2 |
| USB (Internal) | USB 2.0 x 4 |
| Serial Ports | COM1, COM2 (RS-232/422/485, 5V/12V/RI); COM3, COM4 (RS-232) |
| Video (Internal) | LVDS x 1, eDP x 1, Inverter x 1 (12V/2A) |
| SATA | SATA 6Gb/s x 1, +5V SATA power connector x 1 |
| Audio Header | 1 x Optional (not available for WiTAS SKU) |
| GPIO / DIO | 8-bit GPIO |
| SMBus / I2C | SMBus/I2C x 1 (default SMBus) |
| SIM Slot | Nano SIM x 1 |
| Smart Fan | 4-wire Smart Fan x 1 |
| Front Panel I/O | HDD LED, Power LED, Power Button, Buzzer, Reset |
| Expansion Slots | • M.2 2280 M-Key x 1 (PCIe 4.0 x4 / SATA) |
| • M.2 3052 B-Key x 1 (PCIe 3.0 x1 + USB 3.2) | |
| • M.2 2230 E-Key x 1 (PCIe 3.0 x1 + USB 2.0, Wi-Fi 6E CNVi) | |
| Additional Expansion | FPC2 x 1 (PCIe Gen4 x4 x2), supports RAID 0 / RAID 1 |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Storage Temperature | -40°C to 85°C (-40°F to 185°F) |
| Humidity | 0% to 90% RH, non-condensing |
| MTBF | 753,493 hours |
| Certifications | CE / FCC Class A |
Ordering Information
| PART NUMBER | GENE-ARH6-A10-0001 | GENE-ARH6-A10-0002 |
| CPU | Intel® Core™ | Intel® Core™ |
| Ultra 7 Processor | Ultra 5 Processor | |
| 255H | 225H | |
| Display | HDMI x 1 | HDMI x 1 |
| DP x 1 | DP x 1 | |
| LVDS x 1 | LVDS x 1 | |
| eDP x 1 | eDP x 1 | |
| LAN | GbE x 1 | GbE x 1 |
| 2.5GbE x 2 | 2.5GbE x 2 | |
| USB | USB 3.2 Gen 2 x 2 | USB 3.2 Gen 2 x 2 |
| USB 2.0 x 4 | USB 2.0 x 4 | |
| Audio | Line-in/Line-out/MIC | Line-in/Line-out/MIC |
| COM | 4 | 4 |
| Storage | SATA x 1 | SATA x 1 |
| Expansion Slot | M.2 2280 M-Key x 1 | M.2 2280 M-Key x 1 |
| M.2 3052 B-Key x 1 | M.2 3052 B-Key x 1 | |
| M.2 2230 E-Key x 1 | M.2 2230 E-Key x 1 | |
| FPC2 x 1 | FPC2 x 1 | |
| TPM | 2 | 2 |
| Power | 9~36V | 9~36V |
| TEMP | 0°C ~ 60°C | 0°C ~ 60°C |
| Others | Nano SIM, GPIO x 8, | Nano SIM, GPIO x 8, |
| SMBUS | SMBUS |
