ASRock Industrial IMB-190 Mini-ITX Skylake iCore i7/i5/i3 Q170 Low Profile SBC

Compare

  • Product Name: Asrock IMB-190
  • Motherboard Form Factor: Mini-ITX
  • CPU: Socket LGA1151 for Intel Core i7/i5/i3/Celeron (Skylake-S)
  • RAM: Supports Dual Channel DDR4 2133MHz, 2 x SO-DIMM, up to 16GB system memory
  • Expansion: 3 x HDMI, 1 x Dual Channel 24-bit LVDS/eDP, 4 x USB 3.0, 4 x USB 2.0, 2 x SATA3, 1 x Mini-PCIe, 1 x PCIe x4 Slot, 1 x mSATA
  • Other features: Gigabit LAN: 2 x Intel LAN, 1 x TPM Header, 12V/19~24V DC-in

Description

Features

  • Socket LGA1151 for Intel Core i7/i5/i3/Celeron (Skylake-S)
  • Intel Gen9 Intel Graphics DX 11/12, OGL4.3/4.4
  • Supports Dual Channel DDR4 2133MHz, 2 x SO-DIMM, up to 16GB system memory
  • 3 x HDMI, 1 x Dual Channel 24-bit LVDS/eDP
  • 4 xUSB 3.0, 4 x USB 2.0, 2 x SATA3
  • 1 x Mini-PCIe, 1 x PCIe x4 Slot ,1 x mSATA
  • Gigabit LAN : 2 x Intel Lan
  • 1 x TPM Header
  • 12V/19~24V DC-in

Product Specifications

 Form Factor
Dimensions – Mini-ITX (6.7-in x 6.7-in)
 Processor System
CPU – Socket LGA1151 for Intel Core i7/i5/i3/Celeron(Skylake-S)
Core Number – (By CPU Max 4)
Max Speed – (By CPU)
L3 Cache – (By CPU)
Chipset – Q170
BIOS – UEFI
 Expansion Slot
PCI
Mini-PCIe – 2 x Mini-PCIe (1 x full size colay with mSATA, 1 x half size, both with USB signal))
mSATA – 1 (colay with full size Mini-PCIe)
PCIe – 1 x PCIe x4 slot
CFast Card Socket
 Memory
Technology – Dual Channel DDR4 2133 MHz SDRAM
Max. – 16G
Socket – 2 x SO-DIMM
 Graphics
Controller – Intel Gen9 Intel Graphics DX 11/12, OGL4.3/4.4
VRAM – Shared Memory
VGA – Supports max. resolution 1920 x 1200
LVDS – Dual channel 24-bit co-lay with eDP, max resolution 1920 x 1200@60Hz
HDMI – HDMI1: Supports HDMI 2.0, max resolution 4096 x 2160@60Hz HDMI2,3: Supports HDMI 1.4a, max resolution 4096 x 2160@30Hz
DVI – No
DisplayPort – No
MultiDisplay – Yes (Triple Display)
 Ethernet
Ethernet – 10/100/1000 Mbps
Controller – 1 x Intel i210 , 1 x Intel i219LM
Connector – 2 x RJ 45
 SATA
Max Data Transfer Rate – SATA3 (6.0Gb/S)
 Rear I/O
VGA – 0
DVI – 0
HDMI – 3
DisplayPort – 0
Ethernet – 2
USB – 4 x USB 3.0
Audio – 2 (Mic-in, Line-out)
Serial – 0
eSATA – 0
PS2 – 0
 Internal Connector
USB – 4 ( 2 x 2.54 pitch header USB 2.0 compliant)
LVDS / inverter IMB-190 – 1/1; IMB-190-E – 0/0
eDP IMB-190 – 0; IMB-190-E – 1
VGA IMB-190 – 1; IMB-190-E – 0
Serial – 4 x RS-232 (COM1, 2 support RS-232/422/485)
SATA – 2 x SATA3 (6.0Gb/s)
mPCIe – 2
Parallel – 0
mSATA – 1
IrDA – 0
GPIO 8-bit – 4 x GPI + 4 x GPO
SATA PWR Output Con – 1
Speaker Header – 1
 Watchdog Timer
Output – From Super I/O to drag RESETCON#
Interval – 256 segments, 0,1,2…255sec/min
 Power Requirements
Input PWR – 12V / 19~24V DC-in (DC Jack / 4-pin ATX PWR Con)
Power On – AT/ATX Supported
– AT : Directly PWR on as power input ready
– ATX : Press button to PWR on after power input ready
 Environment
Temperature – 0ºC – 60ºC

The specification is subject to change without notice in advance. The brand and product names are trademarks of their respective companies. Any configuration other than original product specification is not guaranteed.
