ASRock Industrial IMB-1211 iCore 8th Gen Coffee Lake Q370 Mini-ITX Motherboard

  • Product Name: Asrock IMB-1211
  • Motherboard Form Factor: Mini-ITX
  • CPU: Socket LGA 1151 for Intel Core i7/i5/i3/Celeron
  • RAM: Supports Dual Channel DDR4 SO DIMM 2400/2666, up to 32GB
  • Expansion: IMB-1211-D: 3 x DisplayPort, 1 x eDP, IMB-1211-L: 2 x DisplayPort, 1 x VGA, 1 x Dual Channel 24-bit LVDS
  • Other features: 4 x USB 3.1 Gen2, 4 x USB 2.0, 4 x SATA3, 5 x COM, 1 x PCIe x16, 1 x Mini-PCIe, 1 x M.2 Key E, 1 x M.2 Key M, 2 x Intel LAN, 1 x TPM 2.0 IC, ATX PWR 24+4-pin, Supports RAID function

Description

Overview

  • Socket LGA 1151 for Intel Core i7/i5/i3/Celeron
  • Supports Dual Channel DDR4 SO DIMM 2400/2666, up to 32GB
  • IMB-1211-D: 3 x Displayport, 1 x eDP
  • IMB-1211-L: 2 x Displayport, 1 x VGA, 1 x Dual Channel 24-bit LVDS
  • 4 xUSB 3.1 Gen2, 4 x USB 2.0, 4 x SATA3, 5 x COM
  • 1 x PCIe x16, 1 x Mini-PCIe, 1 x M.2 Key E ,1 x M.2 Key M
  • 2 x Intel LAN
  • 1 x TPM 2.0 IC
  • ATX PWR 24+4-pin
  • Supports RAID function

Specifications

Form Factor
Dimensions Mini-ITX (6.7-in x 6.7-in)
Processor System
CPU Socket LGA 1151 for Intel Core i7/i5/i3/Celeron
Chipset Intel Q370
Expansion Slots
PCIe 1 xPCIe x16 (Support riser card)
Mini-PCIe 1 x Full/Half mini-PCIe with PCIe x1 and USB 2.0
mSATA N/A
M.2
1x M.2 (Key E, 2230) with PCIe x1, CNVI and USB2.0 for Wireless
1x M.2 (Key M, 2242/2260/2280) with PCIe x4 and SATA3 for SSD
Memory
Technology Dual Channel DDR4 2400/2666 MHz
Max. 32 GB
Socket 2 x SO-DIMM
Graphics
Controller Intel HD Graphics (By CPU)
VGA IMB1211-L: Supports max resolution up to 1920×1200@60Hz
DVI N/A
LVDS IMB1211-L: Supports max resolution up to 1920×1200@60Hz
HDMI N/A
DisplayPort Supports max resolution up to 4096×2304@60Hz
MultiDisplay Triple Display
eDP IMB-1211-D: Supports max resolution up to 4096×2304@60Hz
Ethernet
Ethernet 10/100/1000 Mbps
Controller 1 x Intel I210, 1 x Intel I219LM
Rear I/O
VGA IMB-1211-L: 1
HDMI N/A
DisplayPort IMB1211-L: 2; IMB-1211-D: 3
Ethernet 2
USB 4 x USB 3.1 Gen2 (10Gb/s)
Audio 2 (Mic-in, Line-out)
Serial 2x COM(RS-232/424/485)
PS2 N/A
Internal Connectors
USB 4 x USB 2.0
LVDS / inverter IMB-1211-L: 1
eDP IMB-1211-D: 1
VGA N/A
Serial 3 x COM(RS-232)
SATA 4 x SATA3 (6.0Gb/s)
GPIO 4 x GPI, 4 x GPO
SATA PWR Output N/A
Speaker Header 1
TPM 1 x Onboard TPM 2.0 IC
Watchdog Timer
Output From super I/O to drag RESETCON#
Interval 256 Segments, 0,1,2…255 Sec/Min
Power Requirements
Input PWR ATX PWR 24 + 4
Power On AT/ATX Supported
AT : Directly PWR on as Power input ready
ATX: Press Button to PWR on after Power input ready
Environment
Operating Temp – 0ºC – 60ºC
Storage Temp -40ºC – 85° C



The specification is subject to change without notice in advance. The brand and product names are trademarks of their respective companies. Any configuration other than original product specification is not guaranteed.
